Archpot Manhattan Cylinder Fire Table LP - FGMANCYLD42-LP

The Manhattan Rectangle Fire Table features a smooth 10″ table top with clean minimalistic look and design. Image features Black Solid finish and Tuscan Reserve Diamond Fire Glass.

DIMENSIONS

42x18

66x18

Burner Options

ARCHPOT Stainless Steel Burner Kit

Item Number: SST-MIDSQR60KIT

 Marine Grade Stainless Steel Spiral Burner (24") • 170K BTUs • 12 Gauge 304 Stainless Steel Support Plate • Key Valve Assembly • Whistle-Free Flex Line x2 • Natural Gas or Propane (Please specify) • Manually Operated (Electronic ignition available) • Assembly Included

Upgrades - Electronic Ignition Systems

1. ARCH FIRE CONTROL SYSTEM-12V FROM ARCHPOT

AFCS-12V • UP TO 240K BTUs • 50VA TRANSFORMER INCLUDED

Flame / Heat Sensor: Electronic
Ignition Type: Hot Surface Ignition (Glow Plug)
Ignition Source: Pilot Burner
Max. Btu Output: 240K Btu/hr
Inlet Size: ½”
Outlet Size: ½”
Operating Voltage: 12 Volts AC
Operating Gas Pressure (Natural Gas): 7″ WC
Operating Gas Pressure (Liquid Propane): 11″ WC

2. ALL WEATHER ELECTRONIC IGNITION SYSTEM-24V (AWEIS) FROM FIRE BY DESIGN

STANDARD CAPACITY : AWEIS-SC • UP TO 290K BTUs • 50VA TRANSFORMER INCLUDED

HIGH CAPACITY : AWEIS-HC • 290 TO 512K BTUs • 50VA TRANSFORMER INCLUDED

Utilize the Standard Capacity for most backyard fire pits and fire tables, and revel in up to 290,000 BTUs of heat–more than enough to keep the crisp evening air at bay for a longer night under the stars. The High Capacity model provides an increased heat output of up to 512,000 BTUs! This model is designed to provide all the warmth you might need for outdoor relaxation, but does require a larger diameter fuel line to keep the fire blazing so bright. For large custom fire features we now offer the Extra High Capacity model with a whopping 1.1million BTUs.

In addition to its fantastic heat output, this ignition system is known for its ability to resist the harshest of weather, including intense rain and strong winds, to keep your fire going. The AWEIS is also compatible with various control systems, such as wall mounted and remote controls, to make the ignition process even more convenient for you (sold separately). Available for both Propane and Natural Gas, this ignition system is both powerful and convenient, and is sure to warm you and your guests during your evenings outdoors.

PRODUCT FEATURES:
Pilot Burner Sizes – 12″ / 18″ / 24″ / 30″ (Extensions available for longer lengths)
24 Volt AC Transformer Included
Standard Capacity: Provides 290k BTUs of Heat and Uses a 1/2″ Gas Inlet and Outlet
High Capacity: Provides 512k BTUs of Heat and Uses a 3/4″ Gas Inlet and Outlet
For Use with Natural Gas or Propane
Uses Hot Surface Ignition (Glow Plug) with Intermittent Pilot
Flame/Heat Sensing Thermopile
LC/Lab Test Certified
Minimum Required Gas Pressure: 0.5 PSI
1 Year Limited Warranty
Compatible with Various Remote Controls (Sold Separately)

ALL WEATHER ELECTRONIC IGNITION SYSTEM-30V DC FROM FIRE BY DESIGN

STANDARD CAPACITY : AWEIS-SC30VDC • UP TO 290K BTUs • + TRANSFORMER

HIGH CAPACITY : AWEIS-HC30VDC • 290 TO 512K BTUs • + TRANSFORMER

Utilize the Standard Capacity for most backyard fire pits and fire tables, and revel in up to 290,000 BTUs of heat–more than enough to keep the crisp evening air at bay for a longer night under the stars. The High Capacity model provides an increased heat output of up to 512,000 BTUs! This model is designed to provide all the warmth you might need for outdoor relaxation, but does require a larger diameter fuel line to keep the fire blazing so bright. For large custom fire features we now offer the Extra High Capacity model with a whopping 1.1million BTUs.

In addition to its fantastic heat output, this ignition system is known for its ability to resist the harshest of weather, including intense rain and strong winds, to keep your fire going. The AWEIS is also compatible with various control systems, such as wall mounted and remote controls, to make the ignition process even more convenient for you (sold separately). Available for both Propane and Natural Gas, this ignition system is both powerful and convenient, and is sure to warm you and your guests during your evenings outdoors.

PRODUCT FEATURES:
For use on fire features with in 5′ of a swimming pool
Pilot Burner Sizes – 12″ / 18″ / 24″ / 30″ (Extensions available for longer lengths)
30 Volt DC Transformer Included
Standard Capacity: Provides 290k BTUs of Heat and Uses a 1/2″ Gas Inlet and Outlet
High Capacity: Provides 512k BTUs of Heat and Uses a 3/4″ Gas Inlet and Outlet
For Use with Natural Gas or Propane
Extra High Capacity: Provides 1.1 Million BTUs of Heat and Uses a 3/4″ Gas Inlet and Outlet
For Use with Natural Gas or PropaneUses Hot Surface Ignition (Glow Plug) with Intermittent Pilot
Flame/Heat Sensing Thermopile
LC/Lab Test Certified
Minimum Required Gas Pressure: 0.5 PSI
1 Year Limited Warranty
Compatible with Various Remote Controls (Sold Separately)

Utility Switch Post

4"x4"x44.5" UTILITY SWITCH POST

HOUSES 2 SWITCHES

Installation and Operation Guide Manuals

AWEIS MANUAL

APF MANUAL BURNER SYSTEM

Colors

Learn More About Archpot Color Finish Options

Additional Options

Fire Media

 Add fire media to your Archpot fire table. Most fire tables will need 1 order of fire media glass or lava rock. Larger tables will need 2 orders. Questions? Call Us!

Fire Glass

• Fire glass is the perfect accessory for both indoor and outdoor gas fire pits, fireplaces and fire tables.
• Glass sizes range from ¼” to 1” with regular and reflective finishes
• 60 lb bag
• For use in Indoor Gas Fireplaces, Outdoor Gas Fireplaces and Outdoor Gas Fire Pits
• Fire Pit Glass is a Decorative and eco-friendly alternative for use In Place of Burning Wood or using fake Logs or lava rock in Open Vented, Natural Gas and Propane Gas fire pits, fireplaces and fire tables.
• Archpot Fire Pit Glass is uniquely Handcrafted to Perfection for Ultimate Brilliance and Reflectivity.
• Archpot glass crystal products produce more heat than ceramic logs or Lava Rock. Guaranteed
• All fire glass is quality inspected by highly trained professionals to ensure impeccable performance, elegant appearance and 100% customer satisfaction

Lava Rock

• Improves flame performance by spreading the gas dispersion in all directions, ideal on its own or as a base layer underneath fire glass or even mixing the lava and glass together
• Gas compatible, for use in indoor and outdoor natural gas and propane fire pits, fireplaces and fire tables
• Eco-friendly and safe for indoor and outdoor applications, no color additives or chemicals
• Hassle-free installation: lava rock is easy to install, simply pour straight from the bag into your fire pit, fireplace or fire table.
• 30 lb bag
• Warning: lava rock may pop or crack while adjusting to changes in temperature, please cover your fireplace or fire pit during the first couple of uses, if lava rock is wet, allow fire pit to burn for 45-minutes prior to coming within 15 ft. of the fire pit, when not in use the fire pit must be covered at all time

. Tumbled Lava Rock

• Pebble size 3/4″ – 1 1/2″
• Sourced from lava fields
• Tumbled Lava Rocks are uniquely formed when hot lava emitted from an active volcano meets the ocean and hardens upon contact.
• Tumbled to create a more uniform shape and unique look
• Tumbled lava rock will not crumble or break down in size.
• Used in natural gas or propane fire applications
